600 MCM DOUBLE STACK CONDUCTORS 2 HOLES ALUMINUM AND COPPER

0 Reviews
SKU
MLTS600

The Brumall MLTS600 is a two-hole set-screw connector specified for aluminum or copper conductors from 600 MCM to 2 AWG. Technical data lists a three-barrel configuration and application-dependent electrical ratings.

  • 600 MCM–2 AWG conductor range
  • Current and voltage ratings
  • Hex-socket set-screw termination
  • Two-hole mounting pattern
  • 6061-T6 aluminum alloy body
  • UL, Canadian, RoHS and REACH compliance

Product Overview

The Brumall MLTS600 is a two-hole set-screw connector specified for aluminum or copper conductors from 600 MCM to 2 AWG. Technical data lists a three-barrel configuration and application-dependent electrical ratings.

Technical Specifications

Product information and specifications for the selected item.

SKU: MLTS600

Product Information

BrandBrumall
SKUMLTS600
CategoryLugs

Key Specs

Maximum Amperage (A)420
Certifications and ListingsUL Listed
Height (in.)2.9
Width (in.)2.47

Electrical & Listings

Maximum Amperage (A)420
Certifications and ListingsUL Listed
Termination typeSet-screw connector with hex-socket screws
RoHS and REACH complianceListed as lead-free and 10-of-10 RoHS and REACH compliant
Canadian certificationCanada Certified; Canada 22.2 No. 65
Aluminum-conductor current rating per wire at 75°C340 A
Conductor range and material600 MCM–2 AWG; aluminum or copper
UL listing standard and categoryUL 486A/B, ZMVV; file E61509
Conductor capacity3 conductors; three barrels
Temperature rating75 °C
Body material and platingHigh-strength, high-conductivity 6061-T6 aluminum alloy; tin-over-copper plating
Application-dependent voltage rating600 V; 2,000 V or up to 35 kV uninsulated, depending on application

Dimensions & Weight

Height (in.)2.9
Width (in.)2.47
Length (in.)5.06
Mounting detailsTwo mounting holes for 3/8-in bolts; 0.406-in hole diameter
